BF-333

SEMAC-S3-V2
Verification Mode: White, Black, Combo List
Lift Control: 1
128-Storey Floor Control: Per SEMAC-S3-V2 system
Floor Control:
Black List: 80 floors (Needs 5 pcs of BF-333)
White List: 128 floors (Needs 8 pcs of BF-333)
Hall Call: 7-storey per SEMAC-S3-V2 system
Cardholders Capacity: 20,000 ~ 50,000 per system
Bypass Time Zone: 10 layers for doors/users access authority
Web-Based Control: Yes
User Type: 5 (Super User / User / Visitor / Defense / Guard)
User Capacity: 20,000
Logs Capacity: 65,000
System Log: 1
Reader Type: RS485 / WG (Needs BF20 / BF50 Relay Box)
LED Indicator: Power / ACT / ERR
Time Sets / Zones / Group: Yes
Holiday Dates: Yes
Access, Event, and System Logs: Yes
Inputs: 3 Inputs
Fire Alarm
Maintenance
External
RS-485: 2
Intercom
BF-333 & RS-485 Reader
Web-Based Management: Yes

Additional Features
RS485 Connection: Over controller and reader
Call Lift: 7
Logs Capacity: 65,000
System Log: 1
Built-in Self-Detection Device: To avoid hand-up
Provide Emergency Mode Contact: Eliminates all floors access control
No Limitation for User Control: Use card number and group setting to control floor, simplifying system integration
Built-in Watch Dog: System halt prevention
Built-in 16 Relay Output: Extendable with BF-333 for more than 16 floors control (up to 128 floors)
Relay Output: 16 (1A / 30V DC)
Emergency Input Contact: Yes, eliminates all floor access control
Operation Power: 9 ~ 24V DC
Rated Current: 800 mA
Operation Temperature: 0°C ~ 55°C
Dimension: 179 x 141 x 29 mm
Weight: 650 g
